DJI T70 50L Liquid Spray Tank
DJI T70 50L Liquid Spray Tank - Image 2

DJI T70 50L Liquid Spray Tank

£300.00

  • 50L high-capacity spray tank
  • Designed for DJI Agras T70P
  • Supports large-area spraying missions
  • Quick-fill, easy-clean design
  • Built for professional farm operations
Categories: ,

DJI Agras T70 50L Liquid Spray Tank

The DJI Agras T70 50L Liquid Spray Tank is a high-capacity, heavy-duty payload reservoir engineered specifically to optimize continuous liquid application workflows on the Agras T70 platform. Boasting a massive 50-liter volume capacity, this tank minimizes frequent refilling stops, maximizing your acreage coverage per flight cycle. Built from premium, blow-molded high-density polymers, its reinforced structure features an expanded multi-channel anti-slosh internal profile that suppresses liquid inertia during high-speed, multi-directional field braking and turning maneuvers.

50-Liter Payload Capacity
Anti-Slosh Internal Baffles
High-Density Corrosive-Resistant Polymer
Agras T70 Native Fit
Quick-Release Lock Architecture

DJI Agras T70 heavy-duty liquid payload tank system profile

Precision Thermal and Fluid Management Integration

To maintain optimal flight stability while carrying up to 50 kg of liquid weight, a payload reservoir must function as a structural extension of the drone. The T70 tank utilizes a custom center-of-gravity design that works in tandem with the aircraft’s active flight controllers to maintain uniform weight distribution from full to empty.

  • Integrated high-accuracy real-time continuous volume sensors provide precise payload telemetry.
  • Extra-wide mouth filling port drastically accelerates mix replenishment times out in the field.
  • Sub-surface structural build resists high impact and deep abrasions during intense daily agricultural usage.

Seamless Field Swap Quick-Release Design

Minimize downtime between battery charge drops. The T70 50L payload unit is equipped with heavy-duty quick-release locking latches, allowing field crews to hot-swap clean liquid reservoirs or transition to a dry granular spreader assembly within moments.

  • Integrated Drainage Filter: Mesh protection prevents system clogging from un-dissolved chemical residue.
  • Hermetically Sealed Caps: Prevents fine mist leakage or accidental splashing over delicate navigation avionics.
  • Chemical Corrosion Matrix: Optimized to safely resist aggressive liquid chemicals, intense fertilizers, and abrasive wash routines.
Close up view of the Agras payload mounting architecture and liquid channel connections

Fluid Dynamics Performance

Inertia Control
Anti-Slosh Core Baffling
Drastically suppresses wave momentum, keeping the drone perfectly balanced during sharp field lines.

Operational Turnaround
Rapid Hot-Swap System
Secures cleanly in seconds, eliminating unnecessary delays during intensive seasonal spraying hours.

Technical Specifications

Payload System Specifications
Liquid Holding Volume 50 Liters (Maximum operating load capacity)
Material Composition Blow-molded high-density, anti-corrosive UV polymer
Mounting Interface Quick-lock direct chassis rail alignment
Internal Stabilization Multi-channel molded anti-slosh fluid baffles
Sensor Compatibility Integrated continuous weight / fluid level telemetry port
Platform Compatibility DJI Agras T70 agricultural drone systems exclusively

Maximize your industrial agricultural spray throughput. Contact the Drone Sales UK commercial enterprise team today for genuine replacements, high-capacity accessories, and seasonal fleet pricing packages.

Enquire About T70 Tank Systems

What is the exact capacity and material of the Agras T70 spray tank?›

The tank holds a maximum volume of 50 litres (50L) of liquid payload. It is manufactured from premium, high-density, blow-moulded polyethylene (HDPE) polymer composite. This choice of material makes the reservoir exceptionally lightweight yet highly resistant to structural cracks and chemical corrosion from concentrated pesticides, herbicides, and liquid fertilisers.

How does the integrated anti-slosh system improve flight safety?›

Liquid payloads moving rapidly inside a tank create severe momentum shifts (sloshing), which can easily destabilise an aircraft. The T70 50L tank incorporates a series of internal moulded structural baffles. These internal walls break up liquid inertia, preventing sudden weight shifts and allowing the flight controller to maintain precise terrain-following accuracy even over steep orchard slopes.

Is the T70 50L tank compatible with the Agras T70P or T50?›

No. The 50L liquid tank is explicitly keyed for the standard **Agras T70** chassis rail system. The larger T70P model uses an upgraded, physically wider 70-litre tank setup, while the older T50 utilizes a completely different latch configuration. Always match your exact model prefix to avoid purchasing incompatible latch footprints.

How does the tank measure remaining liquid levels?›

The tank houses dual, high-precision weight and electronic liquid-level sensors at its base. These sensors transmit real-time data directly to the RC Plus controller, giving the pilot an exact percentage readout of the remaining volume. This allows the DJI Fly App to dynamically calculate the exact point to trigger an automated Return-to-Home (RTH) sequence for a payload refill.

Does the tank feature a quick-release design for fast field swapping?›

Yes. The tank utilizes an advanced toolless quick-release locking mechanism. In under 30 seconds, operators can unlatch the tank, disconnect the quick-plug plumbing lines, and slide it off the airframe. This allows a field crew to immediately swap a depleted liquid tank for a freshly pre-mixed secondary tank, or easily switch out the liquid system entirely for a granular spreading hopper.

What is the best way to clean and maintain the 50L tank?›

Critical Field Maintenance: Flush the tank thoroughly with clean, fresh water at the end of every working day to clear out chemical residues that could clog internal lines or damage the base seals. The tank is equipped with an extra-wide top filling neck and an integrated mesh strainer basket, allowing for effortless debris filtering and manual interior washing.

Can Drone Sales UK supply replacement tanks and internal gaskets?›

Yes. Drone Sales UK carries full enterprise spares for the DJI Agras lineup. We stock the complete 50L liquid tank assemblies, replacement base valve couplings, anti-leak silicone O-rings, and inlet filter baskets to keep your operations running smoothly through the peak spraying seasons.

DJI AGRAS T70 50L Liquid Spray Tank · 50-Liter Nominal Capacity · High-Density Anti-Corrosion Polyethylene · Dual-Channel Weight Sensors · Integrated Real-Time Liquid Level Gauge · Fast-Release Modular Locking Design · Anti-Slosh Internal Baffling · Heavy-Duty Bottom Drain Valve · Oversized Top Feeding Port

DJI AGRAS T70 50L Liquid Spray Tank — Technical Specifications

The primary liquid payload module for the standard DJI Agras T70 agricultural platform. Precision-engineered from heavy-duty High-Density Polyethylene (HDPE), this 50-liter tank provides the ideal weight-to-volume balance for medium-to-large-scale farming operations, maximizing fluid dynamics and ensuring repeatable application accuracy.

True 50 L Volume Capacity
50 kg Rated Max Liquid Payload
High-Density Polyethylene (HDPE)
Dual-Pump Magnetic Coupling Inlet
Anti-Slosh Internal Baffling
Quick-Release Hot Swap Mounts
Fluid Capacity & Operational Metrics
  • Volumetric Volume: 50 Liters true storage volume (distinguished from the larger 70L tank native to the T70P upgrade variant).
  • Operating Liquid Payload: Rated strictly for 50 kg of uniform liquid payload distribution.
  • Structural Takeoff Profile: Optimizes aircraft weight distribution when paired with the DB1580 Intelligent Battery, ensuring a lower, highly stable center of gravity during aggressive pitch changes.
  • Dead Space Efficiency: Internal sump geometry minimizes unpumpable fluid residue, ensuring nearly 100% of the batch mixture is actively deployed.
Material Architecture & System Plumbing
  • Hull Material: High-Density Polyethylene (HDPE) molded matrix, engineered for complete resistance to corrosive pesticide formulations, water-soluble fertilizers, and thick herbicide suspensions.
  • Internal Stability: Integrated anti-slosh vertical baffling prevents abrupt internal fluid momentum shifts, preserving flight handling integrity up to the drone’s 20 m/s maximum operating speed.
  • Pump Integration: Native physical routing tailored specifically for the dual magnetic-drive impeller pump system, sustaining bulk flow rates of up to 30 L/min (Standard 2 nozzles) or 40 L/min (Optional 4 nozzles).
  • Filtration Layering: Features a high-flow basket mesh strainer beneath the primary neck ring to catch large foreign particulates during manual mixing or field-tender filing.
  • Turnaround Mounts: Rugged slide-and-lock retention tabs allow for instant, tool-free payload swaps between chemical spraying containers and the 100L granular spreading system.

* Max takeoff weights are actively managed by the Agras avionics architecture. While the T70 frame can technically lift more, filling the 50L tank past its designated upper internal volume limit can cause chemical overflow from the atmospheric vent line during high-acceleration flight maneuvers. Always triple-rinse the internal HDPE tank wall surfaces with clean water following the conclusion of any daily spray operation.
