DB2160 Air-Cooled Heat Sink

£539.00

Air-cooled battery cooling accessory
Designed for DB2160 batteries
Improves charging efficiency
Helps reduce battery temperatures
Built for DJI Agras T100 operations

Categories: DJI Agras T70, Uncategorized

DB2160 Air-Cooled Heat Sink for Agras T70P

The DB2160 Air-Cooled Heat Sink is an essential thermal management upgrade engineered specifically for the high-output smart charging systems of the DJI Agras T70P agricultural drone. Designed to counteract severe heat buildup during continuous, rapid field-charging cycles, the DB2160 utilizes a heavy-duty anodized aluminum fin profile paired with an integrated high-RPM forced-air cooling fan. This system accelerates thermal dissipation, protecting vital charging circuitry and ensuring your turnaround times remain uninterrupted during peak spraying seasons.

Agras T70P Compatible
Forced-Air Active Cooling
High-Density Thermal Fins
Plug-and-Play Integration
Industrial-Grade Shielding

DB2160 Air-Cooled Heat Sink mounted on Agras T70P charging infrastructure

Continuous Field Charging Without Thermal Throttling

Agricultural spray missions demand rapid battery deployment. When smart chargers operate at maximum wattage out in the sun, internal temperatures can spike rapidly, forcing the charger into a protective slow-charge state. The DB2160 completely eliminates this performance bottleneck.

Premium high-density aluminum alloy fins maximize surface area exposure
Heavy-duty mesh-sleeved umbilical power loom seamlessly integrates with the factory power distributor
On-board LED status indicator provides immediate visual confirmation of active cooling power

Rugged, Vibration-Resistant Construction

Built to survive the harsh realities of agricultural utility work, the DB2160 features a precision-milled chassis designed to mount securely without rattling or flexing during transport over rough terrain.

Sealed Fan Motor: Dust and moisture-resistant fan architecture keeps dirt, chemical spray mist, and debris out of the bearings.
Direct Bolt-On Fit: Matches the exact structural mounting points of the T70P system, removing the need for messy modifications or secondary adhesives.
Smart Power Regulation: Draws power directly from the station to dynamically scale its cooling speed based on overall thermal demands.

Close up view of the high-RPM cooling fan and aluminum dissipation fins

Thermal Efficiency Performance

Active Dissipation Scale

Substantial Temperature Drop

Drastically lowers safe core operating temperatures to prevent high-amp safety cutoffs.

Cycle Turnaround Improvement

100% Continuous Output

Maintains optimal peak-amperage charging speeds even in high ambient summer heat.

Technical Specifications

Hardware Architecture
Model Profile	DB2160 Active Air-Cooled Assembly
Compatible Platforms	DJI Agras T70P Smart Charging Systems
Heatsink Base Material	High-thermal conductivity anodized aluminum alloy
Cooling Core Type	High-volume, multi-blade active extraction fan
Wiring Protection	Abrasion-resistant industrial braided mesh sleeving
Status Monitors	Integrated LED system power indicator

Protect your fleet charging ecosystem from thermal degradation. Contact our commercial enterprise team today for hardware compatibility lists, volume discounts, and full seasonal breakdown support.

Enquire About the DB2160 Cooling System

Why is an air-cooled heat sink necessary for the DB2160 battery?›

During ultra-fast charging (pulling massive current to recharge from 30% to 95% in under 9 minutes), lithium-ion cells generate immense thermal energy. If the battery is too hot, the charger will throttle the speeds to protect the cells. The heat sink forces rapid airflow through the battery, dropping temperatures quickly so you can maintain maximum charging efficiency without long cooling delays.

Which batteries and aircraft are compatible with this heat sink?›

The unit is tailored specifically for the DJI DB2160 Intelligent Flight Battery (41 Ah, 52 V). This battery is the native power source for flagship heavy-lift platforms including the DJI Agras T100 agricultural drone and the DJI FlyCart series logistics drones.

How does it fit into a continuous field workflow?›

It is designed to unlock a continuous two-battery or three-battery loop. While one pack is in the air powering a flight, the second pack rests on the heat sink dock inside your generator or charging hub. By the time the aircraft lands, the charging battery has been cooled down, topped off, and is completely ready for immediate swap-out.

How is the DB2160 Air-Cooled Heat Sink powered?›

The heat sink integrates seamlessly with DJI’s commercial power ecosystem. It is powered directly via the dedicated cooling radiator ports on the DJI D14000iE Multifunctional Inverter Generator or the DJI C12000 Intelligent Power Supply, requiring no external third-party power bricks.

Does the heat sink protect the long-term health of the battery?›

Yes. Excessive heat is the number one cause of premature lithium battery degradation and swelling. By preventing the core cells from dwelling at high temperatures during back-to-back sorting cycles, the heat sink helps operators reach the full target lifespan of up to 1,500 charge cycles, dramatically lowering total cost of ownership.

Is the housing rugged enough for harsh farm and field environments?›

Absolutely. It features a heavy-duty, impact-resistant injection-moulded shell reinforced with an internal aluminium interface surface. The assembly is built to handle dirt, dust, and damp field conditions typical of UK farming operations, and it features a quick plug-and-play mounting rail for fast setups.

Can Drone Sales UK provide complete charging combos?›

Yes. Drone Sales UK supplies the DB2160 Air-Cooled Heat Sink as a standalone part or bundled inside complete heavy-duty field kits. These packages typically include the D14000iE fuel-powered generator, DB2160 batteries, and custom heavy-duty trailing systems designed for rapid farm deployment.

DJI DB2160 Air-Cooled Heat Sink · Triple-Channel High-Airflow Architecture · Reinforced Aluminum Cooling Surface · Durable Injection-Molded Outer Housing · Direct Plug-and-Play Battery Interface · Powered via D14000iE or C12000 · Weatherproof Construction · Active Thermal Dissipation · Weight ~6.5 kg

DJI DB2160 Air-Cooled Heat Sink — Technical Specifications

The ultimate thermal management system for high-intensity agricultural drone operations. Engineered specifically for the heavy-duty DB2160 Intelligent Flight Battery, this air-cooled heat sink integrates seamlessly with the D14000iE Inverter Generator and C12000 Smart Charger to dissipate extreme heat, enabling ultra-fast charging and minimizing field turnaround times.

Tailored for DB2160 Batteries
High-Velocity Air Ducts
12V/6A Auxiliary Power Link
Enables 8-Minute Fast Charging
IP55 Agricultural Dust/Water Shield
Industrial Heat Dissipation

Thermal Performance & Integration

Active Dissipation: Uses high-pressure, forced-air cooling channels to aggressively lower core cell temperatures during extreme power input phases.
Generator Coupling: Connects directly to the dedicated air-cooled radiator charge port (12 V / 6 A) on the D14000iE Multifunctional Inverter Generator.
Turnaround Optimization: Essential for achieving the official 8 to 9-minute rapid charge cycle (30% to 95%) on the massive 41,000 mAh DB2160 battery.
Cell Health Protection: Maintains internal battery temperatures within the safe rapid-charging window (15 °C to 75 °C), preventing thermal throttling and extending overall battery life.

Physical Construction & Environmental Protection

Structural Compatibility: Precision-molded frame tailored exclusively to the dimensions and physical contact points of the DB2160 battery pack.
Ingress Protection: Built to IP55 standards to withstand harsh agricultural environments, ensuring resistance to heavy fertilizer dust, fine soil particles, and residual pesticide vapors.
Operating Temperature Threshold: Rated for reliable continuous operation in ambient field temperatures ranging from 0 °C to 40 °C.
Heavy-Duty Wiring: Built with heavy-gauge, abrasion-resistant power cables and ruggedized quick-connect couplings designed for hundreds of hot-swaps per season.

* Continuous use of the air-cooled heat sink is highly recommended for all back-to-back spraying and spreading workflows. Real-world thermal reduction performance depends heavily on ambient air temperatures, relative humidity, and the initial depletion state of the DB2160 Intelligent Flight Battery. Always keep cooling vents clear of mud and dense leaf debris.
