DJI Agras T50

Innovation Above All.
Precision. Sustainability. Progress.

Why choose Agras T50?

For large fields, estates and contractor work, T50 delivers high flow-rate spraying, powerful spreading, and confident navigation with phased-array radar, binocular vision and RTK-ready workflows.

High-volume liquid application — 40 L tank; up to 16 L/min with the standard dual atomising sprinklers, or 24 L/min with the optional four-sprinkler kit.
Granular performance — 75 L hopper / 50 kg payload, up to 108 kg/min output (material-dependent) for seed and fertiliser.
Coverage — indicative rates up to ~21 ha/hour in broadacre; orchard work typically ~4 ha/hour (setup-dependent).
Sense & avoid — front/rear active phased-array radar & binocular vision for obstacle bypassing and steep-slope terrain-follow.
Fast turnarounds — DB1560 batteries with high-power charging enable ~9–12 min recharges to sync with refill cycles.

Figures are indicative and depend on product, rate, height, speed, overlap and conditions. Always follow the label, HSE/CRD guidance and CAA rules.

Frequently Asked Questions

How many hectares per hour can the T50 cover?

As a guide, up to ~21 ha/hour in broadacre with efficient refills and favourable conditions; orchards are closer to ~4 ha/hour. Your results will vary with rate, swath, terrain, wind and turnaround time.

What spray width and droplet sizes are available?

Dual atomising sprinklers (LX8060SZ) support approx. 50–500 µm droplets with an effective spray width around 4–11 m at ~3 m height (setup-dependent).

Can it spread seed or granular fertiliser?

Yes. The 75 L/50 kg spreader handles typical 0.5–5 mm granules and can output up to 108 kg/min. Low-rate gates support precision seeding or light applications.

Is the T50 suitable for hilly terrain and orchards?

Yes. Phased-array radar and binocular vision enable obstacle bypassing and steep-slope terrain-follow for practical orchard and hillside operations.

What charging setup do I need for all-day work?

Use a high-power field charger (e.g., C10000-class) with multiple DB1560 batteries and an air-cooled heat sink. Typical recharge cycles are ~9–12 minutes on 220–240 V, matching refill times.

Do I need RTK? Can I share routes with other Agras drones?

RTK is recommended for accuracy and repeatability and is required for certain FPV mapping modes. Routes can be shared across Agras models with parameter checks before flight.

What licences or approvals are required in the UK?

Agras operations are in the Specific category (CAA). Typically you need a GVC, a CAA Operational Authorisation (SORA-based safety case), appropriate PA certification for spraying, and EC-compliant aviation insurance.

Can I operate in wind or light rain?

Plan for suitable weather windows. Adhere to the manual’s wind limits, avoid heavy rain, and keep appropriate height and speed to maintain coverage quality.

How many people are needed to run a T50 efficiently?

One pilot can fly. A second person to manage refills and batteries significantly boosts productivity on larger jobs.

What about transport and farm logistics?

The airframe folds to fit pickups/vans. Typical field kits include a water bowser, chemicals or granules, PPE, batteries, charger/generator, and a level staging area.

Technical Specifications — Agras T50

Application Payloads	Spray: 40 L tank, up to 40 kg payload. Spread: 75 L hopper, up to 50 kg payload.
Spraying — Atomising System	Sprinklers: LX8060SZ (×2 standard; optional 4-sprinkler kit). Droplet size: approx. 50–500 µm. Effective spray width: ~4–11 m at ~3 m height (setup-dependent). Max flow: 16 L/min (2 sprinklers), up to 24 L/min (4 sprinklers).
Spreading System	Volume: 75 L; Internal load: 50 kg. Material size: typical 0.5–5 mm granules. Output: up to 108 kg/min (material-dependent).
Sensing & Avoidance	Front & rear Active Phased-Array Radar + Binocular Vision for multi-directional sensing and obstacle bypassing. Terrain-follow capable for steep, uneven ground in operation.
Surveying & Mapping	FPV/route surveying supported; RTK recommended for accuracy and required for certain mapping modes. Slope support suitable for typical orchard and hillside planning.
Power & Charging	High-power field charging (e.g., C10000-class) with DB1560 batteries; indicative recharge time ~9–12 minutes on 220–240 V when paired with appropriate cooling.
Remote & Control	DJI RC Plus (7″ high-brightness), RTK-ready workflows; modes for A/B lines, orchards, boundaries; route sharing across Agras series with parameter checks.

High-Volume Spraying (40 L Tank)

Built for big acres and contractor workloads, the Agras T50 delivers consistent, high-rate liquid application with atomised droplets.

Dual atomising sprinklers: up to ~16 L/min; optional 4-sprinkler kit supports higher throughput (~24 L/min).
Controlled droplets: approx. 50–500 µm range to match labels and targets.
Wide, even swath: effective width around 4–11 m (setup-dependent).
Repeatable lines: RTK-ready routes help maintain coverage consistency across seasons.

High-Capacity Spreading (75 L / 50 kg)

Precision granular application for seed and fertiliser with throughput to keep pace on large jobs.

Large hopper: 75 L volume with 50 kg internal load.
High output: up to ~108 kg/min (material-dependent) with even distribution.
Low-rate control: smaller gates support seeding and low-dose work.
Field-ready: updated fenders and drive help protect props and maintain consistency.

Smart Sensing, Terrain-Follow & Fast Turnarounds

Keep operations smooth in varied terrain and minimise downtime between sorties.

Multi-direction sensing: front/rear phased-array radar plus binocular vision for obstacle bypassing and terrain-follow.
Orchard & hillside ready: confident height holding over uneven ground.
Quick cycle times: high-power charging with multiple batteries enables ~9–12 min top-ups (setup-dependent).
Contractor workflow: foldable frame, FPV situational view, and route sharing across Agras series.

Smart Remote Controller with Sunlight-Readable Display (T50)

The DJI Agras T50 is operated with the DJI RC Plus—a fast, multi-core controller designed for the DJI Agriculture app. Intelligent route planning reduces unproductive, full-load ferrying to boost field efficiency, while the 7-inch high-brightness screen stays clear in bright, midday conditions. Switch to Manual at any time for precise headland work or spot treatments, and use RTK-ready workflows for repeatable lines and accurate application across seasons.

DJI Agras T25 — Overview

The DJI Agras T25 is a compact, foldable agricultural drone for UK farms, delivering precise spraying and spreading with RTK positioning and advanced obstacle sensing. Pair it with the DB800 battery and C8000 battery station for rapid turnarounds and near-continuous operation.

Spray/Spread: 20 L spray tank or 35 L spreader (25 kg payload)
Precision: RTK accuracy (±10 cm) & phased-array radar with binocular vision
Throughput: Fast battery swaps; ~9–12 min typical charge with suitable setup

Upgrade coverage with the Atomised Sprinkler System (2 → 4 sprinklers; up to ~24 L/min) and tailor granular work with the T25 Spreading System.

Frequently Asked Questions

What is the spraying capacity and flow rate of the DJI Agras T25?

Tank capacity is 20 L. Expect up to ~16 L/min with two atomising sprinklers, or up to ~24 L/min with the four-sprinkler upgrade (task and setup dependent).

What is the typical spray width (swath) of the T25?

Commonly ~4–7 m at ~3 m AGL with two sprinklers. Actual swath varies with droplet settings, speed, height, and conditions.

How accurate is the T25 with RTK enabled?

With RTK, typical hover/location accuracy is around ±10 cm, supporting repeatable lines and precise return-to-point refills.

What flight times should I expect?

Flights are short, workload-focused sorties. Time per mission depends on payload, speed, wind, and task. Rapid charging with the C8000 and multiple DB800 batteries enables near-continuous operation.

How many people are needed to run the T25 efficiently?

One qualified pilot can fly. For larger jobs, a second person handling refills and battery swaps maximises throughput.

What droplet sizes does the T25’s atomising system support? Are they adjustable?

Approx. 50–500 µm, with selectable presets (Very Coarse → Extremely Fine) and setup-based adjustments. See the Atomised Sprinkler System.

Can I upgrade the T25 from two to four sprinklers?

Yes — install the Atomised Sprinkler Upgrade for wider coverage and higher flow (up to ~24 L/min).

What’s the capacity and recommended spreading range?

The hopper holds 35 L with up to 25 kg internal load. Adjust spinner RPM, outlet size, and altitude to achieve a recommended working range of 4.5–7 m. Learn more.

Does the T25 Spreading System support powders?

No. It is designed for granular materials (e.g., seeds, fertiliser). Powders are not supported. See the T25 Spreading System.

How do I work at low application rates (e.g., small seeds or granular herbicide)?

Fit the small hopper gate, reduce spinner RPM and flight speed, and run a quick flow calibration in the DJI Agras app before the job. Spreading System details.

What are the key features of the DB800 battery for T25?

High-capacity 15,500 mAh pack with LED fuel-gauge, diagnostics, multiple protection features, auto-balancing, storage discharge, and thermal management (IP54). View DB800.

How should I store and maintain DB800 batteries?

Use storage mode for longer periods, keep within recommended temperatures, and avoid prolonged full charge when not flying. Inspect contacts and keep dry/clean. DB800 battery.

How do I activate the C8000 in the app?

Connect the C8000 Battery Station to power, link it to the remote via USB-C (C8000) to USB-A (remote), power on both, then open the DJI Agras app and follow activation prompts.

How do I update C8000 firmware?

With the C8000 powered and cabled to the remote, open the DJI Agras app and follow the on-screen update flow. Keep the remote online and do not disconnect until the update completes.

Comprehensive Specifications

Aircraft

Weight: ~25.4 kg (without battery); ~32 kg (with battery)
Max take-off weight (sea level): ~52 kg (spraying); ~58 kg (spreading)
Dimensions:
- Arms/props unfolded: 2,585 × 2,675 × 780 mm
- Arms unfolded, props folded: 1,475 × 1,540 × 780 mm
- Folded: 1,050 × 690 × 820 mm
Wind resistance: up to ~6 m/s (operational)
RTK accuracy (typical): ±10 cm (H/V)

Positioning & Link

GNSS/RTK: GPS, Galileo, BeiDou (RTK enabled)
Controller: RM700B with 7.02" 1200-nits display
Transmission (CE): up to ~4 km (unobstructed); DJI Relay supported

Spraying System

Tank capacity: 20 L (liquid)
Standard sprinklers: Dual atomising; upgradeable to four sprinklers
Droplet spectrum: ~50–500 µm (setup-dependent; presets available)
Flow rate: up to ~16 L/min (2 sprinklers); up to ~24 L/min (4 sprinklers)
Typical swath: ~4–7 m at ~3 m AGL (scenario-dependent)

Spreading System (T25)

Spreading system weight (incl. tank & fenders): 3.9 kg
Spread tank volume: 35 L
Internal load (payload): 25 kg
Spreading range: tune by material size, spinner RPM, outlet size, and altitude; recommended working range 4.5–7 m
View the T25 Spreading System

Sensing & Avoidance

Phased-array radar: Front & rear; multi-directional sensing and terrain follow
Binocular vision: Close-range obstacle detection (within specified speed/height limits)

Power & Charging

Flight battery: DB800 — 15,500 mAh, 52.22 V (~6.6 kg), 809 Wh
Battery features: LED fuel-gauge, diagnostics, short-circuit & charge-error protection, auto-balancing, storage discharge, thermal management (IP54)
Battery warranty: up to 1,500 cycles or 12 months (whichever occurs first)
Charging station: C8000 (CHX101-7000), 2 channels, up to 7,200 W (dual-input)
Typical charge time (DB800): ~9–12 minutes with a suitable high-output setup

Atomised Sprinkler Upgrade (T25)

Configuration: Expands from 2 to 4 atomising sprinklers — buy the upgrade
Droplet spectrum: ~50–500 µm (preset levels available)
Max flow (with 4 sprinklers): up to ~24 L/min (setup-dependent)
Reverse directional spray: Supports spraying while reversing to reduce turn-time at row ends

C8000 Intelligent Battery Station

Model: CHX101-7000
AC input: 90–264 V AC
DC output: 42–59.92 V DC
Max power: up to 7,200 W (dual-input) / 3,600 W (single-input)
Channels: 2 independent outputs
Protections: Over-temp/voltage/undervoltage, short-circuit, fan stall; connector protection
View C8000 Battery Station

DB800 Intelligent Flight Battery

Nominal voltage / capacity: 52.22 V / 15,500 mAh (809 Wh)
Chemistry: Li-ion NMC (LiNiMnCoO₂)
Ingress protection: IP54 + board-level potting
Compatibility: Agras T25/T25P/T20P/T30
Buy DB800 Battery

DJI Agras T25 — Video

Embed your demo or in-field spraying/spreading video here (YouTube/Vimeo/hosted). Recommended: UK orchard/vineyard and small-field workflows.

Foldable, Flexible, Field-Ready

The DJI Agras T50 uses a reinforced, folding airframe built for contractor-grade workloads. Quick-release arms and a compact transport mode make it easy to load into pickups, vans, or trailers and deploy at the field edge. Despite its 40 L spray tank and 75 L spread hopper, the T50 unfolds fast for confident take-offs and landings in tight farmyards and narrow headlands.
