DJI T100 C12000 Intelligent Power Supply (EMC)

The DJI C12000 is a high‑capacity intelligent power supply designed for the Agras T100 agricultural drone. It delivers up to 12 kW output for ultra‑fast batterycharging, enabling rapid turnaround between sorties. :contentReference[oaicite:1]{index=1}

When paired with the DB2160 battery, the C12000 can recharge from ~30% to ~95% in approximately 8‑9 minutes under ideal three‑phase input conditions. This dramatically reduces downtime in high‑throughput operations. :contentReference[oaicite:2]{index=2}

For maximum performance, the unit requires a three‑phase AC supply (175‑520 V) to achieve full 12 kW output. It supports single‑phase (200‑264 V) operation at reduced power (~3 kW), which may be suitable for smaller operations but will increase charge time. :contentReference[oaicite:3]{index=3}

Dimensions: 456 × 291 × 107 mm. Weight: ~13.13 kg. Output voltage: 62 V. Rated current: 194 A. Rated power: 12,000 W (three‑phase) / 3,000 W (single‑phase) under typical input conditions. :contentReference[oaicite:4]{index=4}

The unit includes advanced protections such as over‑temperature, over/under‑voltage, short‑circuit and fan‑stall detection. Its rugged field‑ready design is suited for agricultural environments, though it should still be deployed in a dry, sheltered site. :contentReference[oaicite:5]{index=5}

By reducing battery recharge time and increasing sortie rate, the C12000 enables more acres to be covered per day. This helps farmers and contractors meet tight windows in UK weather conditions and maximise drone utilisation.

The charger is primarily specified for the Agras T100’s DB2160/DB1580 battery series, though compatibility with other DJI batteries should be verified through official documentation before use. :contentReference[oaicite:6]{index=6}

Ensure the unit is placed on a stable, level surface with adequate ventilation. Route the 1.8 m heavy‑duty charging cable properly, protect from ingress, and ensure the AC supply is properly earthed. For remote sites, use a suitably rated generator or three‑phase connection.

You can order the C12000 via UK‑authorised DJI Agriculture resellers. We provide UK stock, warranty support, training and rapid‑service parts to keep your fleet operational.
